Beam Moving Fixture

Outline
DLW 400L BEAM is a professional moving head beam light fixture, is a computerized lamp beam fixture that is small, lightweight, flexible in operation. It’s equipped a powerful arc-lamp light source, with a standard power of 370W and the maximum power of 380W, lifespan as long as 6000 hours. The lamp power can be linear dimming unlimited between half power and maximum power, allows the lighting engineer freely set the power of lamp as much as a half to fit for different occasions, different colors and brightness. In the sleep mode, the lamp power can be reduced to 150W, saving energy and reducing heat generation. At the same time, take advantage of energy-saving mode, the standby power of the lamp is reduced by 50% compared with the full power lighting, has significantly reduced the electricity cost.
In brief, DLW 400L BEAM help reducing carbon footprint, is a modern moving head beam light.

● Light source: MSD Platinum 300S Flex
● Zoom range: 2°
● One color wheel
● One static gobo wheel
● 6-color plate
● Dual prisms
● One frost filter
● Motorized strobe
● Motorized dimmer

Category:

Description

Electrical

Input voltage: AC200-240V 50/60Hz

Input Power: 520W, PF≥0.98

Maximum input current: 2.6 A



Light Source

Light source: MSD Platinum 300S Flex

Expected lifespan: 6000 hours

Color temperature: 7800K



Optics & Photometric Data

Zoom range: 2°



Color System

One color wheel, 14 color filters + open, can rotate in both directions, rainbow, stepping, sliding gradient color modes



Gobo System

One static gobo wheel, 11 gobos + 7 circle-shaped opens, effects of water flow, shake



Effect Configuration

One frost effect

Fast strobe, multiple strobe speeds, multiple strobe options, pulse, asynchronism, synchronism, random slow, medium, fast speed

Dual prism wheels (8-facet prism + 16-facet prism), 6-color plate for further effects, overlayable with each other to achieve multiple prism effects, rotating in both directions.



Fixture Movement

PAN=540° – 16 bit

TILT=260° – 16 bit



Electronic Control

Channel: 18 Ch/ 24 Ch/ 16 Ch

Control Protocols: DMX512, RDM

Control Portals: XLR-3 + XLR-5

Menu display: 1.77″ color LCD screen; choice of Chinese and English language, menu available to be displayed 180° reversely

Support Software update via DMX cable

Bidirectional data transmission, RDM remote device management

Eco mode (sleep mode when standby)

Energy saving and environmental friendly, power automatically decreases when shut down the bulb.



Size & Weight

Fixture size: 389X271X589 mm

Fixture weight: 18 KG

Flight case size: 960X525X745 mm (2 positions)

Flight case weight: 38 KG



Working Conditions

Minimum and maximum ambient temperature: -20℃~ 40℃

Protection rating: IP20

Specifications and documentation subject to change without notice.
